CDCZ-B2 Semi-automatic 1-4L weighing filling machine is controlled by a PLC program, which can automatically count incoming bottles, automatically peel and weigh, measure, and fill. The equipment has a high degree of automation. Each filling head is equipped with a weighing automatic feedback system, which can set the quantitative setting of each head’s filling volume or fine-tune and correct a single head to ensure metering. The whole machine is made of stainless steel, and the submerged fast and slow filling can effectively reduce the generation of foam. The pipeline adopts a quick assembly method, which is convenient to disassemble and clean. It is suitable for weighing and dispensing 10-50kg of water, edible oil, lubricating oil, fine chemicals, pesticides, and other products.

Overview of CDCZ-B2 Semi-automatic 1-4L weighing filling machine

1. The weighing instrument is a special controller for quantitative packaging scale, with fast response, high precision, and complete functions.
2. The load cell adopts Toledo intrinsically safe sensor, multi-layer medium seal, strong anti-eccentric load capability, dustproof, waterproof, explosion-proof, button-resistant, corrosion-resistant, and meets IP67 sealing standards.
3. The part in contact with the material is made of 304L stainless steel and PTFE material, which is acid-resistant and corrosion-resistant. Special materials can be customized according to the nature of the material.
4. The flow of the material is controlled by the double-speed ball valve and the bottom valve of the spray gun, which is accurate and reliable. The user can adjust the filling speed through the instrument keyboard.
5. All valves can be closed automatically when the air pressure is insufficient or the power is cut off.
6. CDCZ-B2 Semi-automatic 1-4L weighing filling machine adopts special software and hardware design, which can effectively prevent material dripping and ensure the cleanliness of filling equipment and packaging containers.

Applications of CDCZ-B2 Semi-automatic 1-4L weighing filling machine

CDCZ-B2 Semi-automatic 1-4L weighing filling machine is suitable for weighing filling of fluid 1-5L, and automatically completes a series of operations such as counting into bottles, weighing filling, and conveying out bottles. It is especially suitable for quantitative filling of water, edible oil, and lubricating oil. It is an ideal packaging machine for food, medicine, cosmetics, and fine chemical industries.

Features of CDCZ-B2 Semi-automatic 1-4L weighing filling machine

1. This machine adopts programmable logic controller (PLC), touch screen operation control, easy to use and adjust.
2. Each filling head has a weighing and feedback system, which can set and micro-adjust the filling volume of each head.
3.CDCZ-B2 Semi-automatic 1-4L weighing filling machine adopts advanced sensing elements, so that there is no filling when there is no barrel, and the main machine will automatically stop and give an alarm when the barrel is blocked.
4. The filling method is submerged, which can effectively reduce the generation of foam and meet the filling of materials with different characteristics.
5. The connection of each pipeline adopts the quick installation method, which is convenient for disassembly and cleaning, and the parts in contact with the material are made of high-quality stainless steel.
6. The structure of the whole machine meets the requirements of GMP, with stable performance, safety and environmental protection, and elegant appearance.
