Working principle of KZ-900 Semi-automatic strapping machine


Nowadays, strapping machines are widely used in society, and those who use them will have a certain understanding of the principles and hype processes of strapping machines, but sometimes using fully automatic strapping without understanding will cause certain problems. If you are troublesome, today Zhengzhou JYD Machine will introduce the working process and principle of the KZ-900 Semi-automatic strapping machine to you.

Workflow of KZ-900 Semi-automatic strapping machine

The belt is sent to the place→receive the binding signal→release the brake, start the main motor→the right top knife rises and press the right belt on the slide plate→the “T”-shaped guide plate retreats→the proximity switch senses the unwinding probe→the main motor stops, The brake pulls in → the baler unwinds the motor to rotate, and the tape is unloaded for 0.35 seconds → the tape is tightened and tied to the object → the main motor is started for the second time, the brake is pulled in → the large swing lever pulls the tape again, tightening the tape → the left acrosome rises , press the lower belt→heating sheet into the middle of the two belts→the middle top knife rises and cuts off the belt→the middle top knife descends→the middle top knife rises again to make the two belts firmly bond→the middle top knife descends, and the left and right top knives drop at the same time →The heating plate resets→The sliding plate moves backward→The “T” guide plate resets → The proximity switch senses the tape feeding probe → The tape feeding motor starts to drive the tape to feed → The large pendulum lever resets → The tape is in place, and the tape head is pushed onto the “T” guide plate The proximity switch senses the dual probes → the main motor stops, the brake is applied → the strapping machine completes a working cycle.

Principle of KZ-900 Semi-automatic strapping machine

After inserting the packaging tape, the machine can automatically complete the binding process of tape gathering, heat sealing, cutting, and unloading; and it has the function of automatic shutdown. KZ-900 a Semi-automatic strapping machine is a machine that uses packing tape to wrap products or packages, then tightens them and fuses the two ends through the thermal effect or connects them with buckles and other materials. It works fast, and efficiently, and saves time and effort, The strapping is of high quality. Ensure that the packages are not scattered due to loose binding during transportation and storage, and at the same time, they should be neatly tied and beautiful.

KZ-900 Semi-automatic strapping machine requirements for lubrication work

Due to the special working environment of the KZ-900 Semi-automatic strapping machine, the lubricating oil is often contaminated, which affects the normal operation of the machine and damages the components. Then, the recycling of clean lubricating oil is the guaranteed condition to ensure the normal and reliable operation of the baler.
